EmbeddedFanless
AIT-E03
AIT-E03
This fanless industrial PC from Artessa IT features Intel Skylake Core i3/i5 processors (6th generation) and delivers robust connectivity with 2x Gigabit LAN, 4x RS-232, and dual displays (VGA/HDMI). With an extended operating temperature range of -20°C to +70°C, aluminum housing, and flexible power input (12-24V DC), the system is ideally suited for demanding industrial environments, IoT gateways, and automation applications.
Processor
Intel Core i5-6200U
RAM max.
up to 16 GB DDR4L
Temperature Range
-20 … +70 °C
Mounting
Desktop, Wall Mount (208 x 100 mm / 208 x 60 mm)
Technical Specifications
Processor & Performance
| Processor | Intel Core i5-6200U |
| CPU Generation | 6th Gen Skylake |
| Cores | 2 |
| Threads | 4 |
| Base Clock | 2.3 GHz |
| Boost Clock | 2.8 GHz |
| TDP | 15 W |
| Chipset | Integrated with Intel SoC |
| CPU Options |
|
Memory
| RAM Type | DDR4L |
| RAM max. | 16 GB |
| RAM Slots | 1× |
| RAM Speed | 2133 MHz |
| RAM Options |
|
Storage
| Storage Slots | mSATA SSD slot |
| Storage Options |
|
Graphics & Display
| Display Outputs |
|
Network & Communication
| LAN Ports | 2× GbE |
| Wi-Fi Standard | Optional WiFi |
| Bluetooth | Optional Bluetooth |
| COM Ports | 4× RS-232/422/485 |
Connectors
| USB Ports |
|
| Audio | Realtek ALC662 |
Power Supply
| Power Input | 12-24V DC |
Mechanical
| Dimensions (mm) | 220 x 145 x 62 |
| Weight | 1.5 kg |
| Mounting | Desktop, Wall Mount (208 x 100 mm / 208 x 60 mm) |
| Color | Grey / Silver / Black (optional) |
| Material | Aluminum Alloy Shell |
Environment
| Temperature Range | -20 °C … +70 °C |
| Humidity | 5%~95%@40°C, non-condensing |
| Vibration Resistance | 1.5 Grms, IEC 60068-2-64, random, 5-500 Hz, 1 hr/axis |
| Fanless | Yes |
Security & Certification
| Certifications | CEFCC Class ARoHS |
| Supported Operating Systems |
|
