Embedded

AIT-E08

This compact embedded PC features 12th Gen Intel Alder Lake processors (i3/i5/i7), up to 64 GB DDR5 memory, and three Gigabit Ethernet interfaces (2x 2.5GbE + 1x 1GbE). With extended operating temperature range (-30°C to +70°C), flexible mounting options (DIN-rail/wall mount), M.2 expansion slots for WiFi/5G/SSD, and wide DC input voltage (9-36V), it is ideally suited for demanding industrial IoT, edge computing, and automation applications.

Processor

Intel Core i7-1255U

RAM max.

up to 64 GB DDR5

Temperature Range

-30 … +70 °C

Mounting

DIN-Rail, Wall Mount

Compare Download Datasheet (PDF)

Technical Specifications

Processor & Performance

Processor	Intel Core i7-1255U
CPU Generation	12th Gen Alder Lake
Cores	10
Threads	12
Base Clock	1.7 GHz
TDP	15 W
Chipset	Integrated with Intel SoC
CPU Options	·Intel Core i3-1215U (12th Gen Alder Lake, 6C/8T, 1.2 GHz, 15W) ·Intel Core i5-1235U (12th Gen Alder Lake, 10C/12T, 1.3 GHz, 15W) ·Intel Core i7-1255U (12th Gen Alder Lake, 10C/12T, 1.7 GHz, 15W)

Memory

RAM Type	DDR5
RAM max.	64 GB
RAM Slots	2×
RAM Speed	4800 MHz

Storage

Storage Slots	·M.2 2280 Key-M (NVMe/SATA) ·2.5" SATA
Storage Options	·120 GB SSD ·250 GB SSD ·500 GB SSD ·2 TB SSD

Graphics & Display

Display Outputs

HDMI x2

Network & Communication

LAN Ports	3× 2.5GbE
Bluetooth	true
COM Ports	2× RS-232/422/485

Connectors

USB Ports	USB 3.2 Gen2 x4
Audio	Realtek ALC897

Power Supply

Power Input

9-36V DC

Mechanical

Dimensions (mm)	190 x 126 x 75
Weight	1.6 kg
Mounting	DIN-Rail, Wall Mount
Color	Grey / Silver / Black
Material	Aluminum Alloy Shell

Environment

Temperature Range	-30 °C … +70 °C
Humidity	10% to 95% (non-condensing)
Vibration Resistance	1.5 Grms, IEC 60068-2-64, random, 5-500 Hz, 1 hr/axis

Security & Certification

TPM	TPM 2.0
Certifications	CEFCC Class AROHS
Supported Operating Systems	·Windows 10 ·Windows 11 ·Linux ·Ubuntu
